Steel Coil and Structural Steel Flatbed Shipping
Steel coil and structural steel flatbed shipping punishes carriers who cut corners. A 44,000 lb coil that shifts six inches in transit can total a trailer and close a highway. Beams that stick past the tail need flags, lights, and in some states a permit before the truck leaves the yard. MigWay is asset-based, runs 400 trucks and 750 trailers, and moves steel across all 48 states with drivers who own the securement on their own load.
Who This Serves
Steel freight is not one customer type. The securement plan changes based on who is loading the truck and what leaves their dock.
- Steel service centers shipping slit coil, sheet, and plate to fabricators on a routing guide
- Structural fabricators moving beams, columns, and trusses to jobsites on a build schedule
- Rebar and mesh producers running bundled product to concrete contractors
- Pipe and tube mills shipping in nested bundles or on cradles
- Scrap and recycling operations moving baled and bundled material to mills
- 3PLs and brokers who need an asset-based carrier behind a steel account rather than another layer of resale
- Port and rail customers pulling imported coil and slab inland from Charleston, Savannah, Norfolk, and Baltimore
What Ships on a Steel Flatbed
Steel loads out heavy and short. A single coil can hit legal weight before it covers a quarter of the deck. That changes how the load is planned.
- Hot rolled and cold rolled coil, eye to sky or suicide (eye to side)
- Slit coil and narrow mults banded on skids
- Plate in stacked lifts, often with dunnage between layers
- Structural beams: W-shapes, channel, angle, HSS tube
- Rebar in bundles, straight lengths and bent shapes
- Pipe and casing on cradles or chocked in rows
- Fabricated assemblies: stair towers, joists, weldments
- Billets, blooms, and slab from mill to processor
Equipment
MigWay runs 48 ft and 53 ft flatbeds and step decks. Coil racks, cradles, chains, binders, edge protectors, and tarps are standard on steel-capable trucks. Trucks are governed at 70 mph. Drop trailer service is available for high-volume shippers who want to load on their own clock.
Coil Securement and Structural Steel Rules
FMCSA 49 CFR 393.120 sets specific rules for metal coils, and general cargo securement under 393.100 through 393.114 covers structural steel. These are not suggestions. A failed roadside inspection puts the load out of service and the delivery date goes with it.
Coil
Coils with eyes crosswise, lengthwise, or vertical each carry their own tiedown pattern. Coils riding eye to side get chains through the eye plus over-the-top restraint. Every coil group needs blocking, chocks, or a rack that prevents rolling in any direction. MigWay drivers inspect and re-check securement within the first 50 miles and every 150 miles or 3 hours after that, as the regulation requires.
Structural steel
Bundles need a working load limit totaling at least half the cargo weight. Long beams need enough tiedowns for length and weight, spaced so no single point takes the whole load. Anything past the tail gets red flags in daylight and lamps at night. Sharp edges get corner protectors so a strap does not part under tension.
Weight distribution
A 45,000 lb coil sitting wrong on a deck overloads an axle group even when gross weight is legal. Placement is a scale problem before it is a securement problem. MigWay drivers scale steel loads before leaving the shipper when the freight sits concentrated in one spot.
Primary Steel Lanes
MigWay runs steel out of the mill and service center belt into the Southeast build markets, and back the other way with fabricated product.
| Origin | Destination | Route | Approx Miles |
|---|---|---|---|
| Pittsburgh, PA | Charlotte, NC | I-79 to I-77 | 450 |
| Cleveland, OH | Greenville, SC | I-77 to I-85 | 630 |
| Birmingham, AL | Charlotte, NC | I-20 to I-85 | 390 |
| Gary, IN | Nashville, TN | I-65 | 420 |
| Charlotte, NC | Philadelphia, PA | I-85 to I-95 | 540 |
| Baltimore, MD | Richmond, VA | I-95 | 150 |
| Houston, TX | Atlanta, GA | I-10 to I-20 | 790 |
| Charleston, SC port | Charlotte, NC | I-26 to I-77 | 210 |
Transit Times
| Scenario | Typical Transit | Notes |
|---|---|---|
| Under 300 miles | Same day | Loaded and delivered inside one HOS clock |
| 300 to 600 miles | 1 day | Single driver, standard 12 to 24 hour lead time |
| 600 to 1,100 miles | 2 days | One reset stop, live tracking throughout |
| 1,100 to 1,800 miles | 3 days | Team option available on tight build schedules |
| Expedited steel | Truck in 4 hours | Line-down and jobsite hold situations |
| Permitted oversize | Add 1 to 2 days | Permit issue plus daylight-only travel windows |
Rate Structure
MigWay rates are flat and all-in. Fuel and all standard charges are included. One number up front, no add-ons.
| Origin | Destination | Rate | Flat All-In |
|---|---|---|---|
| Pennsylvania, New York, Delaware | Maryland, Virginia, the Carolinas, West Virginia, DC | $3.00/mi | $1,600 |
| Ohio, Indiana, Kentucky, Michigan | Maryland, Virginia, the Carolinas, West Virginia, DC | $4.00/mi | $2,000 |
| Ohio, Indiana, Kentucky, Michigan | Alabama, Georgia, Tennessee, Mississippi | $4.00/mi | $2,000 |
| North Carolina | New York, Pennsylvania, Delaware | $3.75/mi | $1,850 |
| North Carolina | Ohio, Indiana, Kentucky, Michigan | $3.00/mi | $1,700 |
| Texas, Arkansas, Louisiana, Oklahoma | Alabama, Georgia, Tennessee, Mississippi | $4.00/mi | - |
| Illinois, Missouri, Nebraska, Kansas | Indiana, Ohio, Kentucky, Michigan | $3.50/mi | $1,900 |
| Same-state and same-region moves | - | - | $1,500 |
Permits on oversize steel are quoted into the flat number before the load books. You see the total, not a base rate that grows later.
Oversized and Permitted Loads
Structural steel goes over legal dimension often. A 60 ft beam on a 48 ft deck is an overhang problem. A wide plate lift is an escort problem in some states and a non-issue in others.
Legal limits before a permit is needed
- Width: 8 ft 6 in on the Interstate system
- Height: 13 ft 6 in in most states, 14 ft in parts of the West
- Length: varies by state; rear overhang triggers flags and lamps well before a permit
- Weight: 80,000 lb gross, 34,000 lb on a tandem group under federal bridge formula
Permit process
MigWay pulls state permits directly. Multi-state runs need a permit per state, and each state sets its own travel window. Several restrict oversize movement to daylight, ban it on weekends and holidays, and close specific routes during construction. Permits typically issue in 24 to 48 hours. Superload steel takes longer and gets scoped before it books.
Escorts
Pilot car thresholds are state-specific. A load that runs clean through Virginia may need a front escort in Pennsylvania at the same dimension. Dispatch maps the whole route against each state's rules and quotes the escort into the flat rate.
Operating Playbook
- Intake: dimensions, weight, coil orientation, pickup window, and any jobsite delivery constraint go in on the first call. Standard lead time is 12 to 24 hours. Expedited puts a truck under the load in 4 hours.
- Equipment and driver assignment: dispatch matches deck type to the freight and assigns a driver with steel experience. Coil work goes to drivers who have done it, not whoever is closest.
- Permits: if the load is over dimension, permits pull before the truck arrives, not after.
- Loading: driver verifies placement against axle weights, sets blocking and chocks, applies tiedowns and edge protection, tarps if the commodity requires it.
- In transit: ELD and GPS give live tracking on every load. Securement re-checks happen at 50 miles and every 150 miles after.
- Delivery: driver confirms the unload plan on arrival, whether that is a crane, an overhead, or a forklift with coil rams. POD comes back the same day.
One dispatcher owns the load end to end. Zero outsourcing means the person who booked it is the person who answers at 2 a.m.
Why MigWay for Steel Freight
- Asset-based: 400 trucks and 750 trailers on the payroll, not a broker board
- Zero outsourcing: MigWay drivers on MigWay equipment, one accountable plan per load
- Flat all-in rates: fuel and standard charges included, no invoice surprises
- 24/7 dispatch: live people, in-house, at any hour
- Live tracking: ELD and GPS on every load
- 48-state service out of Charlotte, NC, with terminals opening in Dayton, OH and Harrisburg, PA
- Drop trailer capable for service centers that load on their own schedule
- EDI capable for shippers running steel on a routing guide
Steel coil and structural steel flatbed shipping runs on securement discipline and a dispatcher who picks up. Call +1-980-255-3200 or reach MigWay at 9349 China Grove Church Rd, Pineville, NC 28134 to price a lane.
Frequently Asked Questions
What flatbed equipment does MigWay use for steel coil?
MigWay runs 48 ft and 53 ft flatbeds and step decks with coil racks, cradles, chains, binders, and edge protection. Trucks pulling steel carry the securement gear the commodity requires. Step decks handle beams and assemblies that break legal height on a standard flatbed.
How much steel can one flatbed carry?
Legal gross is 80,000 lb, which puts most flatbed payloads between 46,000 and 48,000 lb depending on tractor and trailer tare. A single heavy coil can hit that limit while covering a fraction of the deck. Placement drives axle weights, so a legal-gross load can still be illegal on an axle group without correct positioning.
Does MigWay tarp steel loads?
Yes. Cold rolled coil, finished product, and anything with a surface finish that rust would ruin gets tarped. Structural beams and rebar often ship open. Tarping is included in the flat all-in rate, not billed after the fact.
What are the coil securement rules?
FMCSA 49 CFR 393.120 covers metal coils specifically, with different tiedown patterns for eyes crosswise, lengthwise, and vertical. Every coil needs blocking, chocks, or a rack that stops movement in all directions. Drivers re-check securement within 50 miles and every 150 miles or 3 hours after that.
Do you handle oversize structural steel?
Yes. MigWay pulls state permits directly for over-width, over-height, over-length, and over-weight steel. Multi-state loads need a permit per state, and each state sets its own daylight and weekend travel rules. Permits typically issue in 24 to 48 hours.
What does steel flatbed shipping cost?
Rates run from $3.00 to $4.60 per mile depending on origin and destination, with flat all-in figures starting around $1,500 on short and same-region moves. Fuel and all standard charges are included in the number quoted. Permits and escorts on oversize freight are priced into that flat rate before the load books.
How fast can MigWay get a truck to a steel mill or service center?
Standard lead time is 12 to 24 hours. Expedited service puts a truck under the load in 4 hours when a fabricator is line-down or a jobsite crane is on the clock. Dispatch is 24/7 and in-house, so the request does not sit in a queue overnight.
Can MigWay pull imported coil and slab from the ports?
Yes. MigWay runs port drayage and inland flatbed out of Charleston, Savannah, Norfolk, and Baltimore. The same asset-based truck can take the load from the terminal to the processor without a handoff. Live tracking runs from the port gate to the final dock.
Do you offer drop trailers for steel service centers?
Yes. Drop trailer service lets a service center load on its own schedule instead of holding a driver at the dock. It works best on repeat lanes with steady volume. Dispatch sets the trailer pool size against your load count.
What states does MigWay cover for steel flatbed?
MigWay offers 48-state service from its Charlotte, NC headquarters, with terminals opening in Dayton, OH and Harrisburg, PA. The heaviest steel volume runs the Pittsburgh, Cleveland, Gary, and Birmingham mill corridors into the Southeast. Call +1-980-255-3200 to price a specific lane.
